Factory defaults:

1. Plug in power adapter
2. Plug in a phone to ‘Phone 1′ port of the SPA-2102
3. Dial ∗∗∗∗
4. You should hear ‘Configuration Option Menu’
5. Dial 73738# (RESET#)
6. Press 1 to confirm the reset

Web management:

1. Dial ∗∗∗∗ into the phone connected to the ATA device
2. You should hear ‘Configuration Option Menu’
3. Dial 7932# then press 1# to enable.
4. Then press 1 to save
5. Hang up when you hear option saved.

IP address:

1. Plug in Ethernet cable to router and wait for several seconds
2. Dial ∗∗∗∗110#
3. Listen to IP Address which is read back to you

České tóny:

• Dial Tone : 425@-10;30(0.33/0.33/1,0.66/0.66/1)
• Busy Tone : 425@-10;10(0.33/0.33/1)
• Ring Back Tone : 425@-10;60(1/4/1)

Dial plan:

• (*xxx|112|15x|11[0-1,3-9]x|1[0,2-4,6-9]xx|[2-9]xxxxxxxxS0|00[1-9]xx.)

Daylight saving:

• start=3/-1/7/2:0:0;end=10/-1/7/3:0:0;save=1
